Everything You Need
3-Axis Milling
VMC travel 800 × 500 × 500 mm. Pockets, slots, contours and drilling in a single setup where possible.
CNC Turning
Lathe capacity Ø 300 × 600 mm. Shafts, bushings and turned features with live tooling for cross-holes.
Automated DFM
Thin walls < 0.8 mm, deep holes > 10× diameter, tight internal fillets < 1 mm — flagged before you order.
Precision Materials
Every material below is stocked and ready to run. Grades, thicknesses and finishes come straight from our inventory system.
| Material | Grade | Machinability | Finishes available |
|---|---|---|---|
| Mild SteelInstant | A36 / IS 2062 | Mild steel | Deburr, Powder Coating, Zinc Plating, Black Oxide, Sand Blasting |
| Stainless Steel 304Instant | 304 / AISI 304 | Stainless | Deburr, Mirror Polish, Sand Blasting |
| Stainless Steel 316Instant | 316 / AISI 316 | Stainless | Deburr, Mirror Polish, Sand Blasting |
| Aluminium 6061-T6Instant | 6061-T6 | Aluminium | Deburr, Anodize (Clear), Anodize (Color), Powder Coating, Sand Blasting |
| Aluminium 5052Instant | 5052-H32 | Aluminium | Deburr, Anodize (Clear), Anodize (Color), Powder Coating, Sand Blasting |
| CopperInstant | C110 ETP | Copper | Deburr, Nickel Plating, Mirror Polish |
| BrassInstant | C260 Cartridge | Brass | Deburr, Nickel Plating, Chrome Plating, Mirror Polish |
| EN8 SteelInstant | EN8 / C45 | Mild steel | Deburr, Zinc Plating, Black Oxide, Powder Coating |
| EN24 SteelInstant | EN24 / 817M40 | Alloy steel | Deburr, Zinc Plating, Black Oxide, Chrome Plating |
Stock is the smallest standard block or round bar that fits your part, picked automatically from the 3D model.
Know What You Pay
Upload your file and get an instant price. Here is what goes into it.
| Material | 1 pc | 10 pcs | 100 pcs |
|---|---|---|---|
| Aluminium 6061-T6Instant | ₹2,900 | ₹697 | ₹540 |
| Mild SteelInstant | ₹2,900 | ₹910 | ₹729 |
| Stainless Steel 304Instant | ₹2,927 | ₹1,605 | ₹1,393 |
| BrassInstant | ₹2,934 | ₹1,656 | ₹1,493 |
Price per part for an 80 × 50 × 20 mm block with a pocket and 4 through holes (85 × 55 × 25 mm block stock), standard turnaround, excl. GST.
You can order a single part. The minimum order value is ₹2,900 per line item (rush orders multiply this). Volume pricing lowers the per-part cost automatically.
| Turnaround | Lead time | Price |
|---|---|---|
| EconomyInstant | 7 working days | 18% less |
| StandardInstant | 3 working days | Standard price |
| ExpressInstant | 2 working days | +35% |
| RushInstant | 1 working day | +75% (more when the shop is busy) |
| Same DayInstant | Same day | +140% (more when the shop is busy) |
Design for CNC Machining
Design parts the machine can reach in the fewest set-ups.
Wall Thickness
Minimum 0.8 mm. Below 0.5 mm the part will chatter or break — our system blocks it.
Internal Fillets
Internal corners need a radius ≥ 1 mm (the smallest end-mill). Sharp internal corners are not possible.
Deep Holes
Holes deeper than 10× diameter need peck-drilling and add cycle time. Beyond 20× they are flagged for review.
How to Order Machined Parts
CAD File
STEP / DXF / DWGQuote & DFM
Real-time pricingManufacturing
CNC / Laser / Bend& Delivery
Pan-India shippingUpload a STEP File
Our CNC analysis engine extracts features, selects stock and calculates cycle time.
Instant Quote
See price per part, DFM warnings and available finishes. Adjust material and quantity.
Machining
CAM programming, fixturing and machining. Multi-setup parts are re-fixtured automatically.
Finish & Ship
Deburring, optional finish (anodise, powder coat, plate), inspection and dispatch.
Technical Questions
Which 3D formats do you accept?
STEP (.step / .stp) for instant pricing. IGES and Parasolid files are accepted via engineer review.
What is the standard tolerance?
± 0.025 mm on critical dimensions, ± 0.1 mm general. Tighter tolerances are quoted by an engineer.
Can you machine plastics?
Not yet in the instant engine. Delrin, HDPE and nylon are quoted by our engineers.
Do you offer turning + milling in one part?
Yes — our engine detects turned features and routes to a lathe with live tooling when it saves a setup.
