Structural Reinforcement

Precision
Dimple Forming

Structural and aesthetic depressions in sheet metal. We provide consistent flanged holes and strengthening dimples with institutional depth control.

Stiffness +40%
± 0.2mm Control
Precision

Operational Status

Hydraulic Forming Line Active

30° - 45°
Standard Angles
0.8 - 3mm
Sheet Range
2.5x T
Minimum Spacing
Verified
Material Flow

Sheet Reinforcement

We provide clean, flared and formed depressions that increase the structural rigidity of lightweight sheet metal components.

Structural Strength

Structural Strength

Engineered dimple patterns that increase sheet stiffness by up to 40% with minimal weight addition.

Surface Uniformity

Surface Uniformity

Strict depth control centers ensuring consistent aesthetic appeal across large-format industrial surfaces.

Secondary Processing

Secondary Processing

Optimized for downstream welding and coating with zero edge deformation around the formed area.

Can't find what you need?

Need custom dimple geometries, anti-slip patterns, or reinforcement for lightweight structures? Our forming experts can optimize your panel designs.

Design for
Metal Forming

Proper spacing and depth prevent material thinning and cracking during the hydraulic forming process.

D1

Minimum Spacing

Maintain a distance of at least 3x the material thickness between the edges of adjacent dimples to prevent sheet warping.

D2

Forming Depth

Maximum dimple depth should not exceed 50% of the dimple diameter to avoid localized material failure.

D3

Edge Clearance

Keep dimples at least 1.5x their diameter away from any cut edge to prevent deformation of the outer geometry.

Dimple Forming Engineering Guide

Flow Analysis

Uniform Material Distribution: 98%

Supported Substrates

We stock a comprehensive range of materials for this service. Filter by category to find your specific requirement.

Acrylic
1.6, 3, 4.5, 5.4, 9.5, 12.7 mm
Aluminium 5052
1, 1.6, 2, 2.3, 2.5, 3.2, 4.7, 6.3, 8, 9.5 mm
Aluminium 6061
1, 1.6, 2, 2.5, 3.2, 4.7, 6.3, 8, 9.5 mm
Balsa Wood
1, 3, 5 mm
Carbon Fiber Plate
1, 1.6, 2, 3, 4, 5 mm
CRCA Mild Steel
0.8, 1.2, 1.5, 1.9, 2.6, 3, 3.4, 4.8, 6.3, 8, 9.5 mm
MDF
3.2, 6.3, 9.5, 12.7 mm
Plywood
3.2, 6.3, 9, 12 mm
Stainless Steel 304
0.8, 1.2, 1.5, 1.9, 2.5, 3.2, 4.7, 6.3, 9.5 mm

The
Forming Path

Our automated hydraulic forming cells ensure batch-to-batch consistency for institutional reinforced components.

Process Visualization
01

CAD Identification

Upload your CAD. Our system identifies concentric circles or depressions and prompts you to select dimple standards.

02

Pattern Optimization

The engine suggests pattern optimizations to maximize stiffness while minimizing material stress.

03

Hydraulic Pressing

Once confirmed, parts are loaded into our automated presses where precision dies execute the forming sequence.

Structural Engineering

Institutional-grade metal reinforcement.

Certified Depth Control
Industrial Rigidity
